Orion OD6025-12HB01A fan
Fan Tubeaxial 12VDC Square – 60mm L x 60mm H Ball 25.0 CFM (0.700m³/min) 3 Wire Leads
Contact us for bulk price
$9,49
-
Standard delivery
Trackable Standard Shipping
6-12 Days
-
DHL Courier delivery
3-6 Days
-
120 days Warranty and Money back Guarantee
Payment Methods:
Description
| MPN: | OD6025-12HB01A |
| Manufacturer: | Orion Fans |
| Voltage – Rated: | 12VDC |
| Air Flow: | 25.0 CFM (0.700m³/min) |
| Noise: | 30.0dB(A) |
| Power (Watts): | 1.8 W |
| RPM: | 3975 RPM |
| Width: | 25.00mm |
| Fan Type: | Tubeaxial |
| Series: | OD6025 |
| Size / Dimension: | Square – 60mm L x 60mm H |
| Static Pressure: | 0.220 in H2O (54.8 Pa) |
| Bearing Type: | Ball |
| Features: | Auto Restart, Speed Sensor (Tach) |
| Termination: | 3 Wire Leads |
| Ingress Protection: | – |
| Operating Temperature: | -4 ~ 149°F (-20 ~ 65°C) |
| Approval Agency: | CE, cURus, TUV, UR |
| Description: | FAN AXIAL 60X25MM 12VDC WIRE |
| Detailed Description: | Fan Tubeaxial 12VDC Square – 60mm L x 60mm H Ball 25.0 CFM (0.700m³/min) 3 Wire Leads |
| Current Rating (Amps): | 0.150A |
| Voltage Range: | 8 ~ 13.8VDC |
| Material – Frame: | Polybutylene Terephthalate (PBT) |
| Material – Blade: | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp.: | 60000 Hrs @ 45°C |
Specification
Overview
| Weight | 1 kg |
|---|---|
| MPN | |
| Termination | |
| Noise |
30.0dB(A) |
| Air Flow | |
| Power (Watts) | |
| Voltage - Rated | |
| RPM | |
| Manufacturer |
