Orion OD9225-24HB01A fan
Fan Tubeaxial 24VDC Square – 92.5mm L x 92.5mm H Ball 53.0 CFM (1.48m³/min) 3 Wire Leads
Contact us for bulk price
$15,19
-
Standard delivery
Trackable Standard Shipping
6-12 Days
-
DHL Courier delivery
3-6 Days
-
120 days Warranty and Money back Guarantee
Payment Methods:
Description
| MPN: | OD9225-24HB01A |
| Manufacturer: | Orion Fans |
| Voltage – Rated: | 24VDC |
| Air Flow: | 53.0 CFM (1.48m³/min) |
| Noise: | 35.0dB |
| Power (Watts): | – |
| RPM: | 2900 RPM |
| Width: | 25.00mm |
| Fan Type: | Tubeaxial |
| Series: | OD9225 |
| Size / Dimension: | Square – 92.5mm L x 92.5mm H |
| Static Pressure: | 0.130 in H2O (32.4 Pa) |
| Bearing Type: | Ball |
| Features: | Speed Sensor (Tach) |
| Termination: | 3 Wire Leads |
| Ingress Protection: | – |
| Operating Temperature: | -4 ~ 176°F (-20 ~ 80°C) |
| Approval Agency: | cURus, TUV |
| Description: | FAN AXIAL 92.5X25MM 24VDC WIRE |
| Detailed Description: | Fan Tubeaxial 24VDC Square – 92.5mm L x 92.5mm H Ball 53.0 CFM (1.48m³/min) 3 Wire Leads |
| Current Rating (Amps): | 0.150A |
| Voltage Range: | 12 ~ 28VDC |
| Material – Frame: | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Material – Blade: | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Lifetime @ Temp.: | 60000 Hrs @ 40°C |
Specification
Overview
| Weight | 1 kg |
|---|---|
| MPN | |
| Termination | |
| Noise |
35.0dB |
| Air Flow | |
| Power (Watts) | |
| Voltage - Rated | |
| RPM | |
| Manufacturer |
